Mô tả

Rated Voltage: 12V

Nominal Capacity: 65.0Ah (C₁₀, 1.80V/cell)

Dimension:

• Length: 348±2mm (13.7 inches)
• Width: 167±2mm (6.57 inches)
• Container Height: 178±2mm (7.01 inches)
• Total Height: 178±2mm (7.01 inches)

Approx Weight: 19.2 Kg (42.3 lbs)

Terminal: M6

Container Material: ABS

Rated Capacity (25°C):

• 69.0 Ah (20hr, 3.45A, 1.80V/cell)
• 65.0 Ah (10hr, 6.50A, 1.80V/cell)
• 55.7 Ah (5hr, 11.4A, 1.75V/cell)
• 51.6 Ah (3hr, 17.2A, 1.75V/cell)
• 43.6 Ah (1hr, 43.6A, 1.60V/cell)

Max. Discharge Current: 650A (5s)

Internal Resistance (25°C): Approx 7.0mΩ

Operating Temp. Range:

• Discharge: -15 ~ 50°C (5 ~ 122°F)
• Charge: 0 ~ 40°C (32 ~ 104°F)
• Storage: -15 ~ 40°C (5 ~ 104°F)

Nominal Operating Temp. Range|: 25±3°C (77±5°F)

Cycle Use:

• Initial Charging Current less than 19.5A
• Voltage: 14.4V ~ 15.0V at 25°C (77°F)
• Temp. Coefficient: -30mV/°C

Standby Use:

• Initial Charging Current less than 19.5A
• Voltage: 13.5V ~ 13.8V at 25°C (77°F)
• Temp. Coefficient: -20mV/°C

Effect of Temp. to Capacity:

• 40°C (104°F): 103%
• 25°C (77°F): 100%
• 0°C (32°F): 86%

Self Discharge:
LP series batteries may be stored for up to 6 months at 25°C (77°F) and then a freshening charge is required.
For higher temperatures the time interval will be shorter.
