Mô tả

Rated Voltage: 12V
Nominal Capacity: 26.0Ah (C20, 1.75V/cell)

Dimension:

• Length: 166±2mm (6.54 inches)
• Width: 175±2mm (6.93 inches)
• Container Height: 125±2mm (4.92 inches)
• Total Height: 125±2mm (4.92 inches)

Approx Weight: 7.8 Kg (17.2 lbs)
Terminal: M5
Container Material: ABS

Rated Capacity (25°C):

• 26.0 Ah (20hr, 1.30A, 1.75V/cell)
• 24.6 Ah (10hr, 2.46A, 1.75V/cell)
• 21.9 Ah (5hr, 4.37A, 1.75V/cell)
• 19.1 Ah (3hr, 6.38A, 1.75V/cell)
• 16.0 Ah (1hr, 16.0A, 1.60V/cell)

Max. Discharge Current: 390A (5s)
Internal Resistance (25°C): Approx 14mΩ

Operating Temp. Range:

• Discharge: -15 ~ 50°C (5 ~ 122°F)
• Charge: -20 ~ 40°C (-4 ~ 104°F)
• Storage: -15 ~ 40°C (5 ~ 104°F)

Nominal Operating Temp. Range: 25±3°C (77±5°F)

Cycle Use:
Initial Charging Current less than 7.8A.
Voltage 14.4V~15.0V at 25°C (77°F)
Temp. Coefficient: -30mV/°C

Standby Use:
Initial Charging Current less than 7.8A.
Voltage 13.5V~13.8V at 25°C (77°F)
Temp. Coefficient: -20mV/°C

Effect of temp. to Capacity:

• 40°C (104°F): 103%
• 25°C (77°F): 100%
• 0°C (32°F): 86%

Self Discharge:
LP series batteries may be stored for up to 6 months at 25°C (77°F) and then a freshening charge is required.
For higher temperatures the time interval will be shorter.
