Mô tả

Rated Voltage: 12V
Nominal Capacity: 18.0Ah (C20, 1.75V/cell)

Dimension:

• Length: 181.5±2mm (7.14 inches)

• Width: 76.5±1mm (3.01 inches)

• Container Height: 167.5±2mm (6.59 inches)

• Total Height: 167.5±2mm (6.59 inches)

Approx Weight: 5.35 Kg (11.8 lbs)
Terminal: T3/T2
Container Material: ABS

Rated Capacity (25°C):

• 18.0 Ah (20hr, 0.900A, 1.75V/cell)

• 17.0 Ah (10hr, 1.70A, 1.75V/cell)

• 15.5 Ah (5hr, 3.10A, 1.75V/cell)

• 13.8 Ah (3hr, 4.59A, 1.75V/cell)

• 11.8 Ah (1hr, 11.8A, 1.60V/cell)

Max. Discharge Current: 270A (5s)
Internal Resistance (25°C): Approx 16mΩ

Operating Temp. Range:

• Discharge: -15 ~ 50°C (5 ~ 122°F)

• Charge: -20 ~ 40°C (-4 ~ 104°F)

• Storage: -15 ~ 40°C (5 ~ 104°F)

Nominal Operating Temp. Range: 25±3°C (77±5°F)

Cycle Use:
Initial Charging Current less than 5.4A. Voltage 14.4V~15.0V at 25°C (77°F)
Temp. Coefficient: -30mV/°C

Standby Use:
Initial Charging Current less than 5.4A. Voltage 13.5V~13.8V at 25°C (77°F)
Temp. Coefficient: -20mV/°C

Effect of temp. to Capacity:

• 40°C (104°F): 103%

• 25°C (77°F): 100%

• 0°C (32°F): 86%

Self Discharge:
LP series batteries may be stored for up to 6 months at 25°C (77°F) and then a freshening charge is required.
For higher temperatures the time interval will be shorter.
